Navistar Engine Diagnostics | Navistar Service Software

A diagnostic and programming service tool for Navistar® Engines.

PC application, Navistar Engine Diagnostics is designed to meet  diagnostic challenges of servicing a mixed truck fleet.

Coverage includes all J1939 International electronic engine systems. Allows you to:
– monitor the control system
– retrieve diagnostic trouble codes (DTC)
-change parameters
– view and graph engine data
– run specialized service bay testing on all engine and aftertreatment systems.

The application also features period updates, ensuring you the most up-to-date coverage.

Software Capabilities
  • Control System Monitoring – View – Record – Save – Play Snapshot Recordings
  • Diagnostic Trouble Codes – Retrieve, View, Clear – HD-OBD Freeze Frame Data
  • HD-OBD Monitors – Monitor Results – Diagnostic Readiness – Monitor Performance Ratio – View, Save Print
  • Service Bay Tests – Key On, Engine Off
    • Actuator Tests
    • Sensor Intermittent Faults
    • Cold Start Test
    • Engine Running – Air Management Test – Cylinder Cutout Test – Engine Fan Test (If Equip) – High Pressure Pump TestAftertreatment System Tests
    • Procedures – Sensor Calibrating – Part Replacement Resets
  • Programmable Parameters – Engine Feature settings – View Programming – Change Programming – Service Interval Reset
Minimum System Requirements:
  • Microsoft® Windows® 2000, Windows XP, Windows Vista, or Windows 7
  • 1GHz Intel Core 2 Duo, AMD Athlon X2 or better
  • 2GB (32-bit) or 4GB (64-bit) of RAM
  • 300MB of available hard disk space
  • 1024 x 768 pixel monitor
  • One or more RP1210A compatible communication devices with SAE J1708 and/or SAE J1939 support

NOTE: Close Navistar Engine Diagnostics (NED) before installing a new version

Recommended Interface Cables
  • NEXIQ Technologies – Link-2
  • Dearborn Group Technologies – DPA 5
  • Noregon Systems, Inc. – DLA, DLA USB
Engine Support
– MaxxForce 5 (2007-2009) – MaxxForce 7 (2007-2009) – MaxxForce 7 (2010-2012)
– MaxxForce 7 (2013-) – MaxxForce DT, 9, 10 (2007-2009)
– MaxxForce DT, 9, 10 (2010-2012)  – MaxxForce DT, 9, 10 (2013)
– MaxxForce 11, 13 (2008-2009) – MaxxForce 11, 13 (2010-2013)
– MaxxForce 15 (2010-2013) – N9, N10 SCR (2014-) – N13 SCR (2013-2014)
– N13 SCR (2015-) – International A26 SCR (2017-)
Navistar Engine Diagnostics

Call us for more details….
